Application Visualization and Control
Yes
Dimensions
1.75" x 17" x 10.5" (HxWxD)
Firewall Inspection Throughput
17.1 Gbps
Full DPI Throughput
5.0 Gbps
Gateway Anti-Malware
Yes
High Availability
Active/Passive with State Sync, Active/Active DPI Sync
Interfaces
8x1GbE, 4x10GbE SFP+, 12x1GbE, 2x40GbE QSFP+ (module)
Intrusion Prevention System (IPS)
Yes
IPS Throughput
17.0 Gbps
IPSec VPN Clients
Maximum 2,000 (Recommended)
Logging
Local, Syslog, SonicWall Analyzer, SonicWall GMS
Maximum DPI Connections
1,250,000
Mobile Connect
Yes
New Connections/sec
40,000
Power Supply
Dual, Redundant, Hot-Swappable Power Supplies
Security Processing Cores
24
SSL VPN Licenses
Includes 2; Maximum 50
Threat Prevention Throughput
7.2 Gbps
URL Filtering
Yes
VPN Throughput
10 Gbps
