Anti-malware Inspection Throughput
700 Mbps
Application Inspection Throughput
1 Gbps
Authentication Methods
LDAP, RADIUS, local database, XAUTH, SSO, TOTP
Dimensions (Inches)
8.9 x 5.9 x 1.4
Encrypted Threat Prevention
HTTPS inspection, SSL decryption and inspection
Firewall Inspection Throughput
1 Gbps
Flash Memory
16 GB
Interfaces
5x1GbE, 1 USB, 1 Console
IPS Throughput
1 Gbps
IPSec VPN Throughput
1.3 Gbps
Logging
Local, Syslog, SonicWall Analyzer, SonicWall GMS
Memory (RAM)
1 GB
MTBF (Mean Time Between Failures)
28 years
Network Zones
16
Operating Temperature
0?? to 40??C (32?? to 104??F)
Power Supply
External AC Adapter
Security Processing Cores
Multi-core architecture
Site-to-Site VPN Tunnels
25
SSL VPN Throughput
300 Mbps
Threat Prevention Throughput
335 Mbps
VLAN Interfaces
50
VPN Tunnels (Max)
20
