Brand
Juniper
Chassis
ACX 7100
Cooling
AFI (Air Flow In)
Dimensions (H x W x D)
1.72 x 17.44 x 18.07 inches
DRAM
8 GB
Flash Memory
16 GB
Forwarding Performance
Processing up to 2 Tbps
Layer Support
Layer 2 and Layer 3
MAC Address Table Size
32,000 entries
Management
CLI, SNMP, RMON
Model
ACX7100-48L-AC-AI
MTBF
500,000 hours
Operating Temperature
0°C to 40°C (32°F to 104°F)
Packet Buffer
32 MB per port
Port Configuration
Multi-rate ports
Port Types
48 SFP56, 6 QSFP56-DD
Power Consumption
Max 600W
Power Supply
AC PSU
Relative Humidity
5% to 95% non-condensing
Storage Temperature
-40°C to 70°C (-40°F to 158°F)
VLANs Supported
4,094 VLANs
