Brand
H3C
Device Type
Switch - 28 ports - Managed
Dimensions (WxDxH)
440 x 220 x 43.6 mm
Flash Memory
256 MB
Humidity Range Operating
10% to 90% (non-condensing)
Humidity Range Storage
5% to 95% (non-condensing)
Interfaces
24 x 10/100/1000Base-T, 4 x SFP+
Jumbo Frame Support
9,216 bytes
Layer Supported
Layer 2 switching, Layer 3 switching
MAC Address Table Size
16K entries
Management
SNMP 1, RMON 2, SNMP 3, SNMP 2c, HTTP, HTTPS, CLI
Model
S5130S-28S-LI
Mounting
Rack-mountable
Operating Temperature
0°C to 45°C
Performance
Switching capacity: 128 GbpsForwarding performance: 95 Mpps
Power over Ethernet (PoE)
Not Supported
Quality of Service (QoS)
Yes
RAM
512 MB
Routing Protocol
Static IPv4 routing, Static IPv6 routing
Security Features
Access Control List (ACL) support, Secure Shell (SSH), Secure Sockets Layer (SSL)
Storage Temperature
-40°C to 70°C
VLAN Support
Yes
