Dimensions
442mm x 420mm x 44.4mm (1U)
Forwarding Capacity
2 Mpps
Humidity
5% to 95% (non-condensing)
LAN Ports
8 x GE Ports
Management Interface
SNMP, CLI, WebUI
Max Concurrent Connections
2 Million
Memory
4 GB
Model
N1 SD-WAN Basic Edition, AR6300
Operating Temperature
-10°C to 50°C (14°F to 122°F)
Performance
Up to 2 Gbps
Power Supply
AC 100V-240V, DC -48V
QoS
Layer 7 Application-Based
Routing Protocols
BGP, OSPF, IS-IS, RIP
Security
Firewall, VPN, Encryption
Software Features
Application Optimization, Traffic Engineering, WAN Optimization
Storage
8 GB
Storage Temperature
-40°C to 70°C (-40°F to 158°F)
Type
SD-WAN Router
VPN Throughput
Up to 1 Gbps
WAN Ports
4 x GE Ports
